Thermal Grease
Thermal Grease is made of Silicon thermally conductive filler, high-temperature synthetic oil, stabilizer and additive and it is characterized by a high thermal conductivity. - A grey or White Silicon substance that apply a thin Layer goes in between LED, Heat sink or Thermal Conductive material before installing a LED MCPCB or Semiconductor. This Layer will reduce air pockets & create the Best Thermal Path, It allows for an efficient transfer & Dissipate of heat from LED or Electronics Components to the surrounding air through Heat sink,
US08IHI40200F
Product Description • Constant current driver for led modules • Input voltage 240VAC • High efficiency >85%(@100% Load) • Power factor >0.98,THD<10%(@100%Load) • For use in combination with luminaries of protection class II. • Protection against Abnormal Operating Conditions Like Input Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Open Voltage Protection, Overload Protection. • Surge protection 4KV • Nominal Life Time: 30,000 hours @ tc ≤ tc max Functions • Application oriented operation for maximum compatibility
US08IPI40200F
Product Description . Constant current driver for led modules . Input voltage 240VAC . High efficiency >85%(@100% Load) . Power factor >0.80(@100%Load) . For use in combination with luminaries of protection class II. . Protection against Abnormal Operating Conditions Like Short Circuit Protection, Brownout Protection, Open Voltage Protection, Overload Protection. . Surge protection 2.5KV . Nominal Life Time: 30,000 hours @ tc ≤ tcmax
US10IHI40250F 250mA
Product Description . Constant current driver for led modules . Input voltage 240VAC . High efficiency >86%(@100% Load) . Power factor >0.98,THD<10%(@100%Load) . For use in combination with luminaries of protection class II. . Protection against Abnormal Operating Conditions Like Input Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Open Voltage Protection, Overload Protection. . Surge protection 4KV . Nominal Life Time: 30,000 hours @ tc ≤ tcmax
US10IPI40250F 250mA
Product Description . Constant current driver for led modules . Input voltage 240VAC . High efficiency >86%(@100% Load) . Power factor >0.80(@100%Load) . For use in combination with luminaries of protection class II. . Protection against Abnormal Operating Conditions Like Short Circuit Protection, Brownout Protection, Open Voltage Protection, Overload Protection. . Surge protection 2.5KV . Nominal Life Time: 30,000 hours @ tc ≤ tcmax
US12IHI40300F 300mA
Product Description . Constant current driver for led modules . Input voltage 240VAC . High efficiency >86%(@100% Load) . Power factor >0.98,THD<10%(@100%Load) . For use in combination with luminaries of protection class II. . Protection against Abnormal Operating Conditions Like Input Over Voltage Protection, Under Voltage Protection, Short Circuit Protection, Open Voltage Protection, Overload Protection. . Surge protection 4KV . Nominal Life Time: 30,000 hours @ tc ≤ tcmax
VS24IHIBLE40600A
Model Number :VS24IHIBLE40600A Product Group :Smart Linear Driver Application Area :Indoor Dimming Interface :BLE MESH Features :Dimable Output Power :12-24W Output Current :300-600mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :28mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
VS24IHIBLECCT40600A
Model Number :VS24IHIBLECCT40600A Product Group :Smart Linear Driver Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, Dimable Output Power :12-24W Output Current :300-600mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :28mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
VS28IHI40700F
Model Number :VS28IHI40700F Product Group :Standard Linear Driver Application Area :Indoor Output Power :28W Output Current :700mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :25mm Lifetime :30000h
VS30ISIBLE5CH122500F
Model Number :VS30ISIBLE5CH122500F Product Group :Smart Linear SMPS Isolation :Isolated Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, 3xCH, 5xCH Output Power :30W Output Current :2500mA Output Voltage :12V Power Factor :LPF Operating Mode :Constant Current, Constant Voltage Type Of Protection :IP20 SELV :SELV60 Height :25mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
VS32IHI40800F
Model Number :VS32IHI40800F Product Group :Standard Linear Driver Application Area :Indoor Output Power :32W Output Current :800mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :25mm Lifetime :30000h
VS36NHIBLE80450F
Model Number :VS36NHIBLE80450F Product Group :Smart Linear Driver Isolation :Non-Isolated Application Area :Indoor Dimming Interface :BLE MESH Features :Dimable Output Power :36W Output Current :450mA Output Voltage :66-80V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 Height :28mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
