US08IHI40200F

Mains Voltage Supply

Rated Voltage Range

240VAC

Rated Frequency

50/60 Hz

Max. Admissible Input Voltage Range(AC)

175-265VAC

Total Harmonic Distortion (THD)

<10% (@Full Load)

Mains Voltage Withstanding Capacity

400VAC for 8hrs (with overvoltage shutdown)

Output Data

Constant current

Output Current Tolerance

±5%

Max Starting Time

<1s

Interface And Dimming Operation

Dimming Interface

None

Power Factor

240V(@ Full Load)

>0.98

Efficiency(typ.)

Full Load

>85%

Protections

Open Circuit

<55VDC

Output Short Circuit Operation

YES

Input Over Voltage Cutoff

320VAC ±10%

Input Under Voltage Cutoff

100VAC ±10%

Connection Terminals

For solid Or stranded wire

Type

Push Terminal

Wire Cross Section

0.5mm2 - 1.5mm2

Wire Stripping Length

8.5mm - 9.5mm

Wire Lengths

Max. Wire Length To Led Module

<1m
