SS05ISI15300W
WATT: 4.5 O/P Voltage VOUT (V):3.-15 O/P Current IOUT (mA) : 300 Efficiency (%): >77 Model Number :SS05ISI15300W Product Group :Standard Compact Driver Application Area :Indoor Output Power 4.5W Output Current :300mA Output Voltage :3-15V Power Factor :LPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :22mm Lifetime :20000h
SS06IHI40150W
Model Number :SS06IHI40150W Product Group :Standard Compact Driver Application Area :Indoor Output Power :6W Output Current :150mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :24.5mm Lifetime 30000h
SS07ISI24300W
Model Number :SS07ISI24300W Product Group :Standard Compact Driver Isolation :Isolated Application Area :Indoor Output Power :7W Output Current ;300mA Output Voltage :12-24V Power Factor :LPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :22mm
SS08IHI40200W
Model Number :SS08IHI40200W Product Group :Standard Compact Driver Application Area :Indoor Output Power :8W Output Current :200mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :24.5mm Lifetime :30000h
SS10IHI40250W
Model Number :SS10IHI40250W Product Group :Standard Compact Driver Application Area :Indoor Output Power :10W Output Current :250mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :24.5mm Lifetime :30000h
SS12IHI40300W
Model Number :SS12IHI40300W Product Group :Standard Compact Driver Application Area :Indoor Output Power :12W Output Current :300mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Type Of Protection: IP20 SELV :SELV60 Height :24.5mm Lifetime :30000h
SS15IHI40350F
Model Number :SS15IHI40350F Product Group :Standard Compact Driver Application Area :Indoor Output Power :14W Output Current :350mA Output Voltage :27-40V Power Factor : HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :22mm Lifetime :30000h
SS15IHIBLECCT40350A
Model Number :SS15IHIBLECCT40350A Product Group :Smart Compact Driver Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, Dimable Output Power :8-14W Output Current :200-350mA Output Voltage :27-40V Power Factor :HPF Operating Mode :Constant Current Height :31mm Type Of Protection :IP20 SELV :SELV60 Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
SS15NHI75200W
Model Number :SS15NHI75200W Product Group :Standard Compact Driver Application Area :Indoor Isolation :Non-Isolated Output Power :6-15W Output Current :200mA Output Voltage :30-75V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 Height :19mm Lifetime :30000h
SS15NHIBLECCT50300F
Model Number :SS15NHIBLECCT50300F Product Group :Smart Compact Driver Isolation :Non-Isolated Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, Dimable Output Power :15W Output Current :300mA Output Voltage :30-50V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :22mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
SS15NHIBLECCT75200F
Model Number :SS15NHIBLECCT75200F Product Group :Smart Compact Driver Isolation :Non-Isolated Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, Dimable Output Power :15W Output Current :200mA Output Voltage :60-75V Power Factor :HPF Operating Mode :Constant Current Type Of Protection :IP20 Height :22mm Lifetime :30000h Powered By :Casambi, Plexilent, Tuya
SS15NSIBLECCT50300F
Model Number :SS15NSIBLECCT50300F Product Group :Smart Compact Driver Isolation :Non-Isolated Application Area :Indoor Dimming Interface :BLE MESH Features :2xCH, Dimable Output Power :15W Output Current :300mA Output Voltage 30-50V Power Factor :LPF Operating Mode :Constant Current Type Of Protection :IP20 SELV :SELV60 Height :22mm Lifetime :20000h Powered By :Casambi, Plexilent, Tuya
