DIP Switch Dimmable Motion Sensor Remote Control For High Bay Light
DIP Switch Dimmable Motion Sensor Remote Control For High Bay Light
Built-in 12 DIP Switch Motion Sensor Dimmer Switch Or Remote Control For UFO Highbay
Features:
1. 5.8GHz microwave motion sensor with dimmable function.
2. Supporting different installation and applications,for surface mounting,traditional LED high bay with aluminium reflector,UFO highbay or linear/triproof highbay light.
3. Max installation height is 15m/49.2ft.
4. All parameters can be setting by remote control.
5. Sensitive and reliable.
6.1-10v dimming.
7. IP 20 with 5 years warranty.
Product Description:
| Operating voltage |
EU version:120-240VAC,50Hz/60Hz American veision:120-277VAC,50Hz/60Hz |
| Switching capacity |
EU version:Incandescent: Max, 800W(120-220Vac); Max, 1000W(220-240Vac) American version:Max,3.0A@120Vac,50/60Hz;Max,2.0A@277Vac,50/60Hz |
| Stand-by power | ≤1w |
| Control method | on/off /1-10v dimming/ remote control(HD02R,HD03R,HD05R) |
| Microwave frequency | 5.8GHz±75MHz |
| Microwave power | <0.3mW |
| Detection area | 50%/100% |
| Hold time | 5s/30s/1min/5min/10min/20min/30min |
| Daylight threshold | 2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable |
| Stand-by period | 0s/10s/30s/1min/5min/30min/+∞ |
| Stand-by dimming level | 10%/20%/30%/50% |
| Control line | EU version:Brown L,Blue N,Yellow L',Black 1-10v-,Red1-10v+ American version:Black L,White N,Red L',Gray 1-10v-,Purple 1-10v+ |
| Mounting height | Max.15m ( 49.21ft ) |
| Deteation range | MaxØ14m/45.93ft |
| Motion detection | 0.5–1,5m/s |
| Packing method |
①the small white box(110*100*105mm), ②paper flat, ③outer carton(465*300*465mm)with drying agent |
| Operating temperature | –35℃–+60℃ |
| IP rating | IP 65 |
| Warranty | 5 years |
| Safty standard | EN61347-1 EN61347-2-13 EN60598-1 |
ON/OFF Control Detection Area Daylight Threshold Remote Control
Warranty 5 years Hold Time 8-15m Highbay Stand-by period stand-by dimming level
Detection Range
This figure indicates the maximum distance at the highest mounting height with 100% sensitivity.
Typical installation height 8-15m.
Mechanical structure
With 12 DIP switch and remote control to set all parameters
1. Automatically ON/OFF function:
Light on when detect movement and off after people leave at night. Applications: Corridor, Staircase.
With sufficient daylight, With insufficient daylight, After the last detection and
even when motion detected, when motion detected, light ON. the present hold time
light remains OFF. elapsed, light OFF.
2. No daylight function
The daylight threshold is set to "Disable".
Light on when detect movement, After people leave, Light off after stand-by period.
Applications: Dim places such as Basement Parking, Underpass.
When motion is detected, After people leave the detection After the last detection and
the sensor will switch on the area, light remains 100% the present hold time
light to 100% brighteness. brightness within hold time. elapsed, light OFF.
3. Function Demo - Dimmable control/Corridor function:
User Notes:
1.Microwave can penetrate walls or glass thinner than 20cm and attenuate if thicker than 20cm.
2. The driver voltage shall be stable and float within 10%.
3. Detection area will be affected by speed of motion, mounting height and movement volume.
4. Conduct test on sunny days without the lampshade which will affect the tested lux value.
Memory & Apply Mode
1. Press "ON/OFF button" to turn on the light or off.
2. To reset the parameters, Please follow the steps as below:
Step 1 - Press ON, to turn on the light if it was off at the start.
Step 2 - Press "Start" to the well-setting sensor.
Step 3 - Press the button of Detection range, Hold time, Stand-by dimming level,
Stand-by period and Daylight threshold one after the other in sequence (Press "+/-" to
set parameters).
Step 5 – Press “Memory” to memorize the settings.
Note: The interval of each parameter setting shall be controlled within 30s.
Isolated Setting Mode
1. Press "ON/OFF button" to turn on the light or off. Press "Scene", the remote will
activate settings that were saved last or remain at the factory default settings.
2. To reset the parameters, Please follow the steps as below:
Step 1 - Press ON, to turn on the light if it was off at the start.
Step 2- Press any button of "Scene", Test" and "Apply" to begin the sensor detection
mode.
Step 3 - Press the button of Detection range, Hold time, Stand-by dimming level,
Stand-by period and Daylight threshold one after the other in sequence.
3. To programme other lights in the array that have similar sensors to the same
programme.
Step 1 - Press "ON" to the second sensor
Step 2 - Press "Apply"
Notes:
1. Settings will be saved automatically and remain until you press reset again.
2. Light will flicker when setting each parameter.
3. The icon will flash when setting the corresponding parameter.
