Ceiling Light Dimmable Motion Sensor DIP Switch Setting Detection Angle 30° - 150°



Dimming Control: Dimming +ON/OFF Function
Operating Voltage: 220-240VAC 50/60Hz
Stand-by Power: <1W
Mounting Height: Max.6M
Operating Temperature: -20℃ ~ +55℃
IP Rating: IP20


Dimming Detector Built-in Microwave Sensor for Ceiling Light with Operating Voltage of 220-240Vac 50/60Hz



Features:

1. Dimming + ON/OFF options

2. Built-in for ceiling light in office, corridor and parking lot.

3. Max Mounting height is 6M.

4. DIP switch setting for more options of hold time, detection area and daylight threshold.

5. Daylight sensor for more intelligently control the light based on the natural light.

6. Max detection range could be 14M(Diameter).

7. Different detected sensitivity for more options of detected height.



Specification:

Operating voltage 220~240 VAC 50/60Hz
Switching capacity Max.400W
Stand-by power <1W
Detection area 10%/50%/75%/100%
Hold time 5s/30s/1min/5min/10min/20min/30min
Stand-by period 0s/10s/1min/10min/30min/1h/∞
Stand-by dimming level 10%/20%/30%/50%
Daylight threshold 2Lux/10Lux/50Lux/Disable
Microwave frequency 5.8GHz±75MHz
Microwave power <0.3mW
Interfaces 6-pole pluggable clamp terminal (L,N,N,L’,1-10v+,1-10v-)for 0.75-1.5mm 2 cable
Mounting height Max.6m(ceiling mounted) Max.3m(wall mounted)
Detection range Max.ø14m(ceiling mounted) Max.20m(wall mounted)
Operating temperature -20°C~+55°C
Detection angle 30°-150°
IP rating IP20
Size 103X45X31mm
Certificate TUV RED CE





Wiring diagram:



Dimensions(mm):



Mechanical Structure(mm):



Detection Coverage :



Settings:



Installation Method (Unit: mm)



Application:

1. Suitable for indoor installation to avoid false triggering due to external factors such as rain, wind or tree swing.
2. Shall not be installed in the place with all four metal shelters and small space (such as
galvanized-iron roof ).
